The Queclink GL300 is a small, waterproof, quad-band GPS asset tracker that can transmit location and status messages from as little as every 5 seconds. The device contains internal lithium batteries with a standby time of up to 400 hours, and can also be connected to external power for long life use. An M-USB Cable is required to upgrade firmware and configure the Queclink GL300N GSM/GPS Tracker.
The Queclink GL300 asset tracker is a small, waterproof, self-contained GPS asset tracker designed to operate on quad band GSM/GPRS networks. It offers a minimum transmission rate of 5 seconds, geo-fencing capabilities, motion and temperature sensing functions and is suitable for use on a variety of assets. In addition to its long-life internal battery power, it allows a connection to an external power supply for long-term use. The current and past movements of the device can be viewed on a Google Earth interface through our online mapping portal, OSAT Track.
Please note that to obtain an accurate location our GSM trackers should be used outside and have a clear line of sight to the sky.
The GL300 is a high quality, compact and waterproof asset tracker which enables you to monitor the exact current location and past movements of your most valuable assets. The GL300 is small enough to use for covert tracking requirements and its portable design allows users to easily mount it to almost any piece of equipment for a variety of tracking requirements.
Using quad band 850/900/1800/1900MHz GSM and GPRS frequencies, the Queclink GL300 can be remotely controlled and configured by text message. Its internal 3-axis accelerometer can instantly alert you to unauthorised movements and its location reporting frequency can be configured from as little as every 5 seconds. It also allows you to monitor external temperature readings.
Using internal battery power, the GL300 is capable of a 400 hours standby time or a 5 minute reporting rate for up to 140 hours. This can be extended permanently by connecting to external DC power for long-term reporting requirements without concern for battery life.
Weighing just 60g and small enough to fit in the palm of your hand or hidden discretely, the Queclink GL300 is ideally suited for all types of tracking including lone worker, vehicle, pet and asset tracking applications.
Queclink GL300 Key Features:
GSM/GPRS Coverage The GL300 tracker operates on quad band 850/900/1800/1900MHz GSM and GPRS frequencies, enabling the device to transmit messages instantly and dependably whenever a connection to a mobile operator’s network is available.
Standard Messaging Mode The GL300 tracker is equipped with Location Based Services (LBS) enabling GPS positioning and reporting. The device can transmit GPS location reports from as little as every 5 seconds and these can be viewed via text or on a Google Earth interface through the OSAT Track mapping portal.
Dust & Water Resistant The GL300 tracker is designed to withstand the harshest weather conditions. Its waterproof enclosure ensures that the device is not damaged by atmospheric moisture or complete immersion.
SOS-Function The GL300 tracker is equipped with a programmable emergency button that activates critical, rapid response when you need it most. When pressed, the SOS button transmits your GPS coordinates and alerts your pre-specified contacts that you require assistance
Follow-Me The GL300 tracker offers a ‘Follow-Me’ function. This enables you to ping the device, wherever it is located, and instruct it to transmit its current GPS coordinates and status (device must be turned on with a network connection to enable this feature to function correctly).
Geo-Fencing In conjunction with OSAT Track, OSAT’s online mapping portal, the GL300 tracker offers a geo-fencing feature. This allows you to predefine a set of geographical boundaries and be alerted by email when the device enters or exits the geo-fenced area.
If you are interested in activating your device with OSAT please complete the contract on this link.
OSAT Track Compatible
Our online mapping portal can track your Queclink GL300N to provide real-time information via your GPS location. Any person provided with the login can become an operator to monitor any number of GSM or satellite assets simultaneously in-real time and historically on both the Basic and Professional plans.
Key benefits include:
Geo-Fencing capabilities (Professional Plan only)
Alert options available, with varying degrees of urgency for operator and device holder
Multiple layer options and map views
Inclusive to all devices with GPS tracking capabilities
Past-tracking data points are always accessible, until the device is de-activated
Mapping and asset grouping customisation options are available
Data Reporting and Scheduling functions
Notifications and alerts can be sent directly to the holder of the device
OSAT Track Basic Mapping
Available from just £6.50 ex VAT a month per device and provides location-based data from your device to the online maps. The tracking equipment determines its location by triangulating a position using GPS (Global Positioning System) and then transmits this information via GSM, Satellite, or VHF to a central server for processing.
Suitable for users with single devices
Pay upfront annually to receive a discounted subscription of £65 ex VAT per year
OSAT Track Professional Mapping
Available from just £12.50 ex VAT month per device and allows you to track multiple devices on the same map in addition to features available on the Basic plan. This plan is essential for businesses or organisers managing multiple devices to be able to track the movements of individuals and assets.
Suitable for users requiring access to multiple devices under one login
Fee is applicable per device
Pay upfront annually to receive a discounted subscription of £140 ex VAT per year
Automated tracking is available on this device meaning contacts back home can follow your journey or you can monitor the movement of your assets.
Once the emergency button is pressed on your beacon, your location will be sent to a rescue coordination centre via satellite. This SOS is then diverted to emergency services near to your location to aid rescue. The location will be continuously sent for a minimum of 24 hours.
*Minimum Duration: Upon activation, subscription fee and/or allowance will be pro‐rated for 1st month. Once deactivation is requested via email, subscription fee and/or allowance are not pro‐rated.
**Minimum Monthly Fee: If SIM is suspended, the minimum monthly subscription fee will continue to be charged. No roll‐over of unused minutes is permitted from one billing period to the next. Please send your request to suspend the SIM via email.
6.85 x 3.85 x 2.35cm
Li Polymer 1300mAh, 3.7V
Without Reporting - 400 hours
5 Minute Reporting - 140 hours
10 Minute Reporting - 180 hours
3.5V to 4.5V
