Thuraya IP NEO
The Thuraya IP NEO is a lightweight, rugged satellite terminal delivering high-speed broadband up to 1024 kbps. Compact and portable, it’s built for government, enterprise, and field teams who need reliable connectivity anywhere.
Description
Elevate your connectivity with the Thuraya IP NEO, a portable satellite broadband terminal built for professionals who need reliable communications in the harshest and most isolated environments. Powered by Cobham’s proven hardware, the IP NEO delivers data speeds up to 1024 kbps, making it ideal for high-demand applications such as VoIP, video conferencing, telemedicine, and IoT/M2M networks.
Lightweight at just 2.2 kg, this compact terminal packs easily into a backpack while providing enterprise-grade performance. Its IP55-rated magnesium casing, rugged connectors, and integrated Wi-Fi hotspot ensure that you can set up quickly and stay connected in any environment.
From federal agencies and first responders to energy companies, healthcare providers, and media crews, the Thuraya IP NEO is trusted worldwide for mission-critical communication. Whether you’re coordinating disaster relief or streaming live video from the field, the IP NEO keeps you connected when it matters most.
Key Features:
- Broadband speeds up to 1024 kbps via the Thuraya 4-NGS satellite
- Compact, battery-powered design (just 2.2 kg)
- Built-in Wi-Fi hotspot and Thuraya Connect App (iOS/Android)
- Rugged IP55-rated casing for durability in extreme conditions
- Rapid deployment, online in seconds
- Supports ISR, C2, IoT/M2M, video streaming, eLearning, telemedicine, and more
Wherever your mission takes you, the Thuraya IP NEO ensures your connection is fast, secure, and always within reach.
Read More
Specifications
| Category | Specification |
|---|---|
| Device | |
| Dimensions (H × W × D) | 225 × 225 × 61.5 mm |
| Weight (incl. battery) | 2.2 kg |
| Data & Voice | |
| Data (Thuraya 4-NGS) | Up to 1024 kbps (Rx/Tx) at > 5° elevation |
| Data (Thuraya 2/3) | Up to 444 kbps (Rx/Tx) at > 5° elevation |
| Voice (Thuraya 4-NGS) | Standard VoIP, Embedded SIP Server |
| RF & GNSS | |
| Frequencies (Tx) | 1626.5–1660.5 MHz |
| Frequencies (Rx) | 1525.0–1559.0 MHz |
| GNSS | GPS, Galileo, Beidou, Glonass |
| Languages & Approvals | |
| Languages | ENG, AR, FR, POR, ES, RU, JP, CN |
| Approvals | CE, RED, RoHS, WEEE, FCC, UL, RCM; Thuraya Type Approval |
| Power | |
| DC input range | 12–24 VDC (max. 10.8–33.6 VDC) |
| PoE input | PoE (802.3bt Type 3 Class 6 via RJ45) |
| PoE output | PoE (802.3at Type 1 Class 2 via RJ45) |
| Power consumption | Standby/Transmit: 4.5 W / 22 W (typical); During charging: 75 W (max.) |
| AC/DC power supply (input) | 100–240 VAC, 47–63 Hz, 64 W |
| AC/DC power supply (output) | 19 VDC |
| Battery type | Lithium-ion (rechargeable) |
| Battery (nom. voltage / capacity) | 10.8 V / 6.9 Ah |
| Battery run time (standby) | Up to 38 hours* |
| Battery run time (receive) | Up to 4 hours @ 1024 kbps* |
| Battery run time (transmit) | Up to 2 hours @ 1024 kbps* |
| Recharge time | < 3 hours (0–100%) |
| Charge temperature | 0°C to 45°C |
| Environmental | |
| Operating temperature (ambient) | −21°C to +55°C |
| Storage temperature | −21°C to +50°C |
| Ingress protection | IP55 compliant |
| Interfaces | |
| WLAN access point | 802.11 b/g/n/ac |
| Ethernet | 2 × RJ45: 1 × PoE input (external power), 1 × PoE output (IP Handset) |
| User interface | 2 × LED (Status, WLAN), Power Button, Reset Button, Web Interface |
| Features | |
| Companion app | Thuraya Connect App (Android / iOS) |
| Router & management | Webserver, NAT Router, Admin control (password protected), DHCP, Network Management, Remote Management, PPPoE |
| Package Contents | |
| In the box | IP NEO C Terminal with embedded Lithium-Ion Battery; AC/DC Power Supply; Euro Power Cord; EU to UK Converter; Quick Start Guide; Ethernet Cable |
* On Thuraya 4-NGS.
