Garmin GPSMAP943XSV 9" Combo No Transducer US and Canada GN+ - OPENED BOX

Garmin GPSMAP943XSV 9" Combo No Transducer US and Canada GN+ - OPENED BOX

$1,525.00

The Garmin GPSMAP 943XSV delivers powerful navigation and sonar performance in one sleek 9" touchscreen unit. With UHD CHIRP sonar, built-in Wi-Fi®, and preloaded U.S. and Canada charts, it’s the perfect choice for serious anglers and boaters seeking precision and reliability on the water.

Please note: The item is in new condition. The outer packaging has been opened and slightly damaged.

THIS PRODUCT IS EX-DISPLAY. STILL IN EXCELLENT WORKING CONDITION. ALL ACCESSORIES INCLUDED. OUTER PACKAGING DAMAGED DUE TO BEING OPENED. INCLUDES SIM CARD READY TO ACTIVATE.

Enhance your time on the water with the Garmin GPSMAP 943XSV 9" Combo, built for serious anglers and boaters who expect precision, reliability, and cutting-edge navigation. This advanced unit features a bright, sunlight-readable 9-inch touchscreen display with intuitive controls for effortless access to charts, sonar, and navigation data.

The GPSMAP 943XSV pairs ultra high-definition Garmin CHIRP sonar with ClearVü and SideVü scanning (transducer sold separately), delivering exceptional underwater clarity to help you identify fish and structure with ease. With preloaded coastal and inland maps for the US and Canada, plus compatibility with premium Garmin charts, you can plan routes confidently and navigate safely wherever you go.

Stay connected and in control with NMEA 2000® networking, wireless smartphone connectivity, and support for Garmin’s advanced marine devices. Whether you’re fishing, cruising, or exploring new waters, the GPSMAP 943XSV is the dependable companion every boat deserves.

Key Features

Display: 9" sunlight-readable touchscreen with intuitive controls
Sonar Technology: Supports CHIRP sonar, ClearVü and SideVü scanning (transducer sold separately)
Preloaded Maps: Includes detailed charts for the US and Canada, compatible with premium charts
Networking: NMEA 2000® compatible, integrates with Garmin devices
Wireless Connectivity: Receive smartphone alerts and connect to compatible Garmin devices
Advanced Navigation: Waypoints, routes, and track logs for safe and precise navigation
Rugged Design: Built for marine environments, easy to install and operate

Specification	Details
Unit Dimensions	9.2" x 6.4" x 3" (23.3 x 16.2 x 7.6 cm)
Display Size	7.8" x 4.4"; 9.0" diagonal
Display Resolution	1280 x 720 pixels
Display Type	WXGA display
Weight	3.6 lbs (1.6 kg)
Water Rating	IPX7
Polarized Support	Yes
Power Consumption	Max: 22 W at 10 Vdc; Typical: 1.3 A at 12 Vdc; Max: 1.8 A at 12 Vdc
Antenna	Internal or external via NMEA 2000
Mounting Options	Bail, flush, or flat
Receiver	10 Hz high-sensitivity
Garmin Marine Network™ Ports	1
Transmit Power	1 kW traditional; 1 kW CHIRP
Preloaded Maps	Garmin Navionics+ offshore, coastal, and inland U.S. & Canada charts
Data Card Support	2 microSD™ cards (back of unit)
Waypoints	5,000
Track Log	50,000 points; 50 saved tracks
Routes	100
Tide Tables	Yes
Garmin Radar Compatible	Yes
Garmin Sonar Compatible	Yes (built-in)
SmartMode Compatible	Yes (customizable monitor presets)
Supports AIS	Yes (tracks target ship positions)
Supports DSC	Yes (displays position data from DSC-capable VHF radio)
Supports Fusion-Link™ Radios	Yes
GSD™ Black Box Sonar Support	Yes
GCV™ Black Box Sonar Support	Yes
ActiveCaptain Compatible	Yes
GRID™ Compatible	Yes
Wireless Remote Compatible	Yes
Sailing Features	Yes
Dual-Frequency Sonar	50/200 kHz
Dual-Beam Sonar	77/200 kHz
Frequencies Supported	Traditional: 50/77/83/200 kHz; CHIRP: low, medium, high; ClearVü: 260/455/800 kHz (dependent on transducer)
CHIRP Sonar Technology	Yes (built-in)
ClearVü	Yes (built-in)
SideVü	Yes (built-in)
Maximum Depth	5,000 ft at 1 kW (dependent on water conditions)
Bottom Lock	Yes
Water Temperature Log & Graph	Yes
Sonar Recording	Yes
Sonar History Rewind	Yes
NMEA 2000® Compatible	Yes
Transducer Pin Numbers	12-pin (orange)
NMEA 0183 Input Ports	1 (Differential)
NMEA 0183 Output Ports	1 (Differential)
Video Input Ports	1 BNC
Wireless Connectivity	Yes
J1939 Compatible	Yes
